Heat Resistant Non Stick PTFE Coated Fiberglass Cloth / Glass Fiber Cloth for Solar Panels

Shop our high-quality Heat Resistant Non Stick PTFE Coated Fiberglass Cloth for Solar Panels. Factory direct pricing. Durable and reliable. Order now!
Request a Quote

PRODUCTS DETAILS

Basic Info.

Model NO.
HTDPTFE
Color
as Customers′ Requirement
Transport Package
Carton Pallet
Specification
0.08mm-0.9mm Thickness
Trademark
HONTED
Origin
China
HS Code
7019
Production Capacity
1000000 Square Meters

Product Description

PTFE coated fiberglass fabric:

Fiberglass fabric coated with PTFE is made up of high-capability fiberglass which has steeped into PTFE. It is a new product with high capability and multiform function of complex material. Fiberglass fabric coated with PTFE has various good capability and it is widely used in aircraft industry, paper manufacture, food, environment protection, print and painting, costume, chemical, glass manufacture, medical, electronic, insulation, building (basic cloth of topping frame), sharpener slice, machinery, etc.
Heat Resistant Non Stick PTFE Coated Fiberglass Cloth / Glass Fiber Cloth for Solar PanelsHeat Resistant Non Stick PTFE Coated Fiberglass Cloth / Glass Fiber Cloth for Solar PanelsHeat Resistant Non Stick PTFE Coated Fiberglass Cloth / Glass Fiber Cloth for Solar PanelsHeat Resistant Non Stick PTFE Coated Fiberglass Cloth / Glass Fiber Cloth for Solar PanelsHeat Resistant Non Stick PTFE Coated Fiberglass Cloth / Glass Fiber Cloth for Solar Panels


Properties:

  1. Stable dimension, high intensity, elongation coefficient less 5%.
  2. Good temperature resistance, 24 hours working temperature -60~300°C
  3. Low coefficient of friction and dielectric constant, good insulating ability
  4. Non stick, easy to clear stains and adhesives on the surface
  5. Good chemical resistance, it can resist all most of chemical medicines, acids, alkalis, and salt, it is fireproof, lower in aging.



Main Specification :



Model

Color

Thickness

Max Width

Weight

Tensile Strength

Temperature

HTD-9008AJ

brown

0.08mm

1250mm

160g/

550/450N/5cm

-140~260°C

HTD-9008BJ

black

0.08mm

1250mm

165g/

550/450N/5cm

-140~260°C

HTD-9008Y

black

0.08mm

1250mm

180g/

550/450N/5cm

-140~260°C

HTD-9013AJ

brown

0.13mm

1250mm

260g/

1100/1000N/5cm

-140~260°C

HTD-9013BJ

black

0.13mm

1250mm

265g/

1100/1000N/5cm

-140~260°C

HTD-9013Y

black

0.13mm

1250mm

265g/

1100/1000N/5cm

-140~260°C

HTD-9018AJ

brown

0.15mm

1250mm

380g/

1200/1100N/5cm

-140~260°C

HTD-9018BJ

brown

0.18mm

1250mm

380g/

1800/1700N/5cm

-140~260°C

HTD-9025AJ

Brown

0.18mm

1250mm

390g/

1800/1700N/5cm

-140~260°C

HTD-9025BJ

Black

0.25mm

2800mm

520g/

2100/1800N/5cm

-140~260°C

HTD-9035AJ

black

0.25mm

2800mm

540g/

2100/1800N/5cm

-140~260°C

HTD-9035BJ

brown

0.30mm

2800mm

610g/

2800/2400N/5cm

-140~260°C

HTD-9040AJ

black

0.30mm

2800mm

510g/

2800/2400N/5cm

-140~260°C

HTD-9040BJ

brown

0.35mm

3200mm

660g/

2600/2300N/5cm

-140~260°C

HTD-9065AJ

black

0.35mm

3200mm

680g/

2600/2300N/5cm

-140~260°C

HTD-9090AJ

brown

0.40mm

3500mm

780g/

3000/2500N/5cm

-140~260°C

HTD-9090BJ

black

0.40mm

3500mm

820g/

3000/2500N/5cm

-140~260°C

HTD-9008AJ

brown

0.65mm

4000mm

1150g/

4400/4000N/5cm

-140~260°C

HTD-9008BJ

brown

0.90mm

4000mm

1550g/

6000/5000N/5cm

-140~260°C

HTD-9008Y

black

0.90mm

4000mm

1650g/

6000/5000N/5cm

-140~260°C


Applications:

1. Used as various of liners to resist high temperature, such as microwave liner, oven liner, or other liners.

2. Used as non stick liners, intermediate

3. Used as various conveyor belts, fusing belts, sealing belts or anywhere need resisting high temperature, non stick, chemical resistance etc.

4. Used as covering or wrapping material in petroleum, chemical industries, as wrapping material, insulating material, high temperature resistance material in electrical industries, desulfurizing material in power plant etc.

Heat Resistant Non Stick PTFE Coated Fiberglass Cloth / Glass Fiber Cloth for Solar Panels

PTFE Fiberglass Mesh Conveyor Belt
 are constructedwith PTFE impreganated coated fiberglass, aramid(or both) and polyester mesh materials that are both durable and food safe. A wide selection of splice, edge and tracking options ensures that belts are constructed in the best way of their intended purpose.

Heat Resistant Non Stick PTFE Coated Fiberglass Cloth / Glass Fiber Cloth for Solar Panels
Heat Resistant Non Stick PTFE Coated Fiberglass Cloth / Glass Fiber Cloth for Solar Panels

Specification:


Model

Mesh Size

Material

Thickness

Weight

PTFE content

Max Width

Tensile Strength

HTD-6001

1x1mm

fiberglass

0.5mm

443g/m²

30

4000mm

310/290N/cm

HTD-6002

2x2mm

fiberglass

0.7mm

443g/m²

30

4000mm

350/310N/cm

HTD-6003

4x4mm

fiberglass

1.0mm

480g/m²

32

4000mm

390/320N/cm

HTD-6004

4x4mm

fiberglass

1.0mm

475g/m²

31

4000mm

390/320N/cm

HTD-6007

4x4mm

fiberglass

+kevlar

1.2mm

600g/m²

31

4000mm

895/370N/cm

HTD-6008

4x4mm

fiberglass

1.0mm

560g/m²

27

4000mm

395/370N/cm

HTD-6012

4x4mm

fiberglass

1.0mm

570g/m²

28

4000mm

395/370N/cm

HTD-6013

10x10mm

fiberglass

1.2mm

360g/m²

24

4000mm

360/300N/cm

HTD-6015

2x2.5mm

fiberglass

0.9mm

520g/m²

20

4000mm

390/320N/cm

HTD-6015S

2*4cm

fiberglass

0.9mm

620g/m²

31

4000mm

650/330 N/cm




Available options for open mesh belt edging:


1. PTFE Film Edging, which encapsulates the edge to stop fraying and offer protection. The advantage of using film is that it is soft in nature and will stretch with the belt when under tension.



2. PTFE Glass Cloth, which edging can be used as a sturdier option to film and a good option if a tracking arm is used to detect the edge of the belt when coming in to contact with it.

3. PTFE Coated Kevlar which is the most durable of the edging types. It is a good option when considering using guiding cord on the belt.

Available options for belt joint:

1.     Bullnose joint, this one can meet the requirement of most belts.

2.     Alligator joint, this joint fit for those belt which need the joint part to be flat

3.     Spiral joint, this one is very light when comparing with alligator join

Application:

1. Drying machine for non-woven textile, textile printing, silk-prnting and dyeing machine.

2. Shrinking machine for garment fabric, high-frequency and UV dryer.

3. Conveyer belt for hot-air dryer, various of food baking, quick-frozen machines.

4. Oiling machine for paper glazing and waxing, plant engineering.

5. Seperating sheet for hardboard production etc.
Heat Resistant Non Stick PTFE Coated Fiberglass Cloth / Glass Fiber Cloth for Solar PanelsPacking & Loading:
Heat Resistant Non Stick PTFE Coated Fiberglass Cloth / Glass Fiber Cloth for Solar PanelsFAQs



1. What is your terms of packing?
    Generally, we pack our goods in carton with pallet

2. What is your tems of payment?
    T/T 30% as deposit, and 70% before delivery. We'll show you the photos of the products and packages before you pay the balance.

3. What is your terms of delivery?

    EXW, FOB, CFR, CIF,L/C at sight

4. How about your delivery time?

    Generally, it will take 21 days after receiving your advance payment. The specific delivery time depends on the items and the quantity of your order.

5. Can you produce according to the samples?

Yes, we can produce by your samples or technical drawings. We can build the molds and fixtures.

6. What is your sample policy?
    We can supply the sample if we have ready parts in stock, but the customers have to pay the sample cost and the courier cost.

7. Do you test all your good before delivery?
    Yes, we have 100% test before delivery
