High Quantity Customized PTFE Coated Fiberglass Dryer Conveyor Belts

High Quantity Customized PTFE Coated Fiberglass Dryer Conveyor Belts available at our factory. Durable and reliable for all your industrial conveyor needs.
Request a Quote

PRODUCTS DETAILS

  • Overview
  • Product Description
  • Product Features
  • Product Application
  • Product Specifications
  • Company Profile
  • Certifications
Overview

Basic Info.

Feature
Oil-Resistant, Acid And Alkali Resistant, Tear-Resistant, Heat-Resistant, Cold-Resistant, Wear-Resistant
Tensile Strength
Strong
Can Be Customized
Yes
Surface Treatment
PTFE Coated
Weave Type
Plain Woven
Color
Black/Brown/White
Transport Package
Rolled in Polybag, Then Packed by Wooden Case
Specification
Black/Brown/White
Trademark
CHANGWEI
Origin
Ningbo, China
HS Code
3919909090
Production Capacity
150000 Square Metres

Packaging & Delivery

Package Size
120.00cm * 40.00cm * 40.00cm
Package Gross Weight
20.000kg

Product Description

High Quantity Customized PTFE Coated Fiberglass Dryer Conveyor Belts

Product Description

PTFE conveyor belt is also known as PTFE fiberglass conveyor belt, PTFE high temperature resistant conveyor belt. PTFE conveyor belts are divided into two types: PTFE Open mesh belt and PTFE fiberglass fabric belt. Both are based on glass fiber fabric coated with PTFE resin to make the base fabric of PTFE conveyor belt. Among them, the specification of PTFE open mesh conveyor belt is defined by the size of the mesh, mainly 1 ×1MM, 2×2.5MM, 4×4MM, 10×10MM and other meshes, and according to the warp and weft, there are single-weft and double-weft PTFE open mesh conveyor belts. PTFE fiberglass fabric conveyor belt is based on different specifications of thickness, the thinnest can reach 0.08 MM.

CHANGWEI uses imported glass fiber as the weaving material, weaves plain weave, twill weave, satin weave or other weaving methods into high-grade glass fiber fabric base material, and then through unique technology, repeatedly fully impregnated, coated with Japanese imported PTFE resin , to produce a variety of thickness and a variety of ultra-wide high temperature resistant varnished fabric. According to customers needs, it is processed into a PTFE Fiberglass Conveyor Belts. Because of its excellent performance, it is widely used in papermaking, food, environmental protection, printing and dyeing, clothing, chemical industry, glass, medicine, electronics, insulation, grinding wheel slicing, machinery and other fields.



Product Features

Main Features of High Quantity Customized PTFE Coated Fiberglass Dryer Conveyor Belts:
1.Weather resistance: It can be used for a long time in a wide temperature range from -60 ºC to +300 ºC, and the aging test of PTFE fluororesin coating is placed at +300 ºC for 200 days, not only the strength will not decrease but also There is no reduction in weight either. On the contrary, it does not age and crack at -180 ºC ultra-low temperature, and can maintain the original flexibility. It can work at +360 ºC ultra-high temperature for 120 hours without aging, cracking, and good flexibility.
2.Non-adhesive: It is not easy to adhere to various substances. Easy to clean all kinds of oil stains, stains or other attachments attached to its surface, almost all sticky substances such as paste, viscous resin, organic paint, etc., can be easily cleaned from the surface of PTFE fluororesin coated high temperature cloth.
3.Mechanical properties: The surface of PTFE fluororesin coated high-temperature cloth can withstand a compressive load of 200kg/cm2, basically without deformation or lack of coils. It has an excellent and extremely low friction coefficient, and the dimensional stability and tensile elongation rate ≤ 5%.
4.Electrical insulation: PTFE fluororesin-coated high-temperature cloth has unique electrical insulation, with a dielectric constant of 2.6 and a dielectric loss tangent below 0.0025.
5.Chemical resistance: It can resist the corrosion of almost all chemical items. PTFE fluororesin-coated high-temperature cloth will not age or deform under strong acid and strong alkali conditions.
6.Resistant to chemical corrosion, strong acid, strong alkali, aqua regia and various organic solvents.
7.Good dimensional stability (elongation coefficient less than 5‰), high strength. Has good mechanical properties.
8.Anti-bending fatigue, suitable for smaller wheel diameters.
9.Fire retardant.

*Thickness: 0.25-1.05mm.
*Width: 300-4200mm. Made according to customer requirements

High Quantity Customized PTFE Coated Fiberglass Dryer Conveyor Belts

Product Application

Main Application Range of High Quantity Customized PTFE Coated Fiberglass Dryer Conveyor Belts:

1.Textile, printing and dyeing: printing drying, bleaching and dyeing cloth drying, fabric shrinkage drying, non-woven fabric drying and other drying channels, drying room conveyor belt.
2.Screen and printing: Loose drying machine, offset printing machine, UV series light curing machine, paper oil drying, ultraviolet drying, plastic product silk screen drying and other drying channels, drying room conveyor belt.

3.Other items: High-frequency drying, microwave drying, freezing and thawing of various foods, baking, heat shrinkage of packaged items, drying of general moisture-containing items, rapid drying of flux-type inks, etc.
*PTFE Open Mesh Conveyor Belts are suitable for hot air occasions and thermal processing transmission conditions.
High Quantity Customized PTFE Coated Fiberglass Dryer Conveyor Belts

Product Specifications



Main Specifications of High Quantity Customized PTFE Coated Fiberglass Dryer Conveyor Belts:

Item

Color

Thickness

Max Width

Weight

Tensile Strength

Temperature

CWF-T0158

Brown/Black/White

0.08mm

1250mm

158±5g/m2

500/480N/50mm

-70~280 ºC

CWF-T0160

Brown/Black/White

0.08mm

1250mm

160±5 g/m 2

620/460N/50mm

-70~280 ºC

CWF-T0180

Brown/Black/White

0.08mm

1250mm

180±5 g/m 2

930/720N/50mm

-70~280 ºC

CWF-T0260

Brown/Black/White

0.13mm

1250mm

260±5 g/m 2

100/1000N/50mm

-70~280 ºC

CWF-T0275

Brown/Black/White

0.13mm

1250mm

275±5 g/m 2

1000/960N/50mm

-70~280 ºC

CWF-T0290

Brown/Black/White

0.13mm

1250mm

290±5 g/m 2

910/880N/50mm

-70~280 ºC

CWF-T0395

Brown/Black/White

0.18mm

1250mm

395±5g/m 2

1600/1600N/50mm

-70~280 ºC

CWF-T0415

Brown/Black/White

0.18mm

1250mm

415±5 g/m 2

1500/1500N/50mm

-70~280 ºC

CWF-T0490

Brown/Black/White

0.25mm

2800mm

490±5 g/m 2

2100/1800N/50mm

-70~280 ºC

CWF-T0510

Brown/Black/White

0.25mm

2800mm

510±5 g/m 2

2800/2700N/50mm

-70~280 ºC

CWF-T0660

Brown/Black/White

0.35mm

3200mm

660±5 g/m 2

2700/2600N/50mm

-70~280 ºC

CWF-T0680

Brown/Black/White

0.35mm

3200mm

680±5 g/m 2

2100/2200N/50mm

-70~280 ºC

CWF-T0780

Brown/Black/White

0.40mm

3500mm

780±5 g/m 2

2900/3100N/50mm

-70~280 ºC

CWF-T0820

Brown/Black/White

0.40mm

3500mm

820±5 g/m 2

3000/2900N/50mm

-70~280 ºC

CWF-T1150

Brown/Black/White

0.65mm

4000mm

1150±5 g/m 2

4200/4000N/50mm

-70~280 ºC

CWF-T1550

Brown/Black/White

0.90mm

4000mm

1550±5 g/m 2

6300/5800N/50mm

-70~280 ºC

CWF-T1650

Brown/Black/White

0.90mm

4000mm

1650±5 g/m 2

6150/5300N/50mm

-70~280 ºC



Company Profile

High Quantity Customized PTFE Coated Fiberglass Dryer Conveyor Belts
China Changwei Group was established in 2001. Changwei is the largest manufacturers of PTFE and silicone soaked products in China, and also as the leader and exploiter in this field. Several kinds of our special products fill up the domestic vacancy. Mr. Wang, the founder and president of Changwei, invented the PTFE Coated Glass Fabric Seamless Belt and applied the patent successfully.This new product solves many problems existing in seam belts. The seamless belts will not easily rupture or distort like seam belts.It is contribution to those customers.
We believe that providing our customers with a consistent level of quality that meets and exceeds their requirements, and by delivering the quality products in a timely manner at the best possible prices, are the keys to make the long-term success of our company.

With more than 20 years experience and with acquired technology from Europeand USA, CHANGWEI's Managers are prepared for the challenge of New ProductDevelopments. Owners of the well known CHANGWEI® Brand of specialized Heat Resistant and Non-Stick Belts, Tapes, Technical Fabrics and Adhesives.
We actively encourage our team to approach a partnership with our customers and employees in a commitment towards continuous improvement and innovation!
High Quantity Customized PTFE Coated Fiberglass Dryer Conveyor Belts

High Quantity Customized PTFE Coated Fiberglass Dryer Conveyor Belts
CHNAGWEI products are widely use in Seamless Antistatic Garment Fusing Belts, Food Processing Belts, Baking Liners & Grilling Surfaces, Tapes for the Aerospace, Automotive and Electronic Industries, Special Technical Fabrics for the constructionof Wind Power Equipment, for the prevention of Corrosion, Packaging Processes and many other application.
Changwei Group supplies the top quality products to more than 50 countries worldwide. We also concentrate in researching and finding solutions to all problems in most industrial processes.
